Vacuum Freeze Dryer FM-VFD-A102 contains 1.5M² drying area with 7 trays, handling 15 to 20kg per batch. Features a -60°C ultra-low cold trap for industrial-grade drying. Equipped with a 7-inch touchscreen and USB data export for process tracking. It possesses a thick, high-transparency acrylic observation door that ensures durability while allowing clear visibility of the drying process. It is designed for heavy-duty freeze-drying applications.
At Dyrec, we are committed to empowering your business with the latest solutions. Our top-quality rotary joints are designed to optimize the performance of your equipment.
Take the next step toward success by contacting us or downloading our comprehensive product guide. Your journey toward success begins here.
| Freeze dried area | 1.5M² |
| Handling capacity | 15 to 20 kg/batch |
| Cold trap temperature | -60°C |
| Maximum ice capacity/water catch | 20kg/24H |
| Shelves spacing | 40mm |
| Number of trays | 7 Pcs |
| Tray size | 270×780 mm |
| Ultimate vacuum | ≤ 2Pa |
| Vacuum pump type | 2XZ-4 |
| Pumping speed | 4L/S |
| Noise | ≤ 60db |
| Power | 3000W |
| Power supply | 220V/50Hz |
| Dimension (L×B×H) | 650×1080×1130 mm |
| Package dimension (L×B×H) | 730×1150×1510 mm |
| Net weight | 197kg |
| Gross weight | 245kg |
