Portable NIR Spectrophotometer FM-PNS-A100 is a compact tool for precise material composition analysis. It has wavelength range of 1000 to 1800 nm and employs diffuse reflectance for detection. Rapid analysis is ensured by the device within less than 10 seconds. Spectrophotometer is a versatile tool offering quick and reliable analysis in a portable and user-friendly package.
At Dyrec, we are committed to empowering your business with the latest solutions. Our top-quality rotary joints are designed to optimize the performance of your equipment.
Take the next step toward success by contacting us or downloading our comprehensive product guide. Your journey toward success begins here.
Portable NIR Spectrophotometer is useful in fields such as agriculture, food processing, pharmaceuticals, and environmental monitoring.
| Wavelength range | 1000 to 1800 nm |
| Wavelength accuracy | ≤ + 0.2 nm |
| Light Source | Tungsten halogen lamp |
| Detector | High performance ultra-cooled lnGaAs (Indium Gallium Arsenide) |
| Bandwidth | 10.95 + 0.3 nm at 1395.5 nm |
| Signal to noise ratio | > 10000:1 |
| Sample Volume | 200 mL |
| Analysis time | 6 to 10 seconds |
| Wavelength repeatability | < 0.05 nm |
| Stray light | < 0.1% |
| Communication | Bluetooth |
| Temperature range | 0 to 40 ℃ |
| Humidity range | 5 to 85 % |
| Power supply | (220 ±20) V/50 Hz |
| Dimensions (L × W × H) | 220 × 310 × 310 mm |
| Weight | 10 kg |
