Portable Multi Gas Analyzer FM-PMG-A100 detects 1-18 types of gases, offering flexible and comprehensive monitoring. It features a 3.5-inch HD LCD screen with a resolution of 320 × 480 for clear data display. Its modular design allows the selection of 1-3 modules, preventing cross interference. The built-in pump ensures faster gas sampling, and multi-layer filtering protects the sensors from oil, water vapor, and dust. Our gas analyzer provides reliable performance for industrial gas detection applications.
At Dyrec, we are committed to empowering your business with the latest solutions. Our top-quality rotary joints are designed to optimize the performance of your equipment.
Take the next step toward success by contacting us or downloading our comprehensive product guide. Your journey toward success begins here.
| Gas Detected | NO, SO₂, CO, CO₂, CH₄ |
| Detection Principle | Electrochemistry (NO, SO₂), Infrared Ray (CO, CO₂, CH₄) |
| Measuring Range | NO: 0 to 5000 ppm SO₂: 0 to 5000 ppm CO: 0 to 50% VOL CO₂: 0 to 25% VOL CH₄: 0 to 50% VOL |
| Resolution | 1ppm (SO₂, NO), 0.01% VOL (CO, CO₂, CH₄) |
| Precision | ≤ ± 2% F.S |
| Display | 3.5-inch HD LCD screen |
| Display Resolution | 320 × 480 |
| Data storage | Independent SD memory card, standard 32G, automatic measurement data record, customizable record time interval |
| Data transmission | RS485 signal output, USB interface data transmission, with PC software, can download storage, analyze and print data |
| Battery | 5200 mAh rechargeable lithium battery |
| Battery Hours | More than 32 hrs with single gas and 24 hrs with six gases together |
| Pump flow rate | 500 mL/min |
| Explosion-proof | Ex Ic IIC T3 Gc |
| Charger | Standard Micro-USB charging port with 9V/2A charger |
| Alarm | Fault alarm and low battery alarm |
| Wireless transmission distance | Bluetooth is less than 10 m, and WIFI outdoor single point is less than 500 m |
| Network frequency | 2.4G high frequency |
| Working Humidity | 0 to 95% RH |
| Temperature | -40℃ to +70℃ |
| IP grade | IP66 |
| Dimension (H × W × D) | 260 × 230 × 120 mm |
| Weight | 3700 g |
