Melting Point Apparatus FM-MP-A101 utilizes PID and PWM technology to provide precise temperature regulation. It has a measurement range of room temperature to 360 ℃ with a resolution of 0.1℃. Temperature and process status may be easily monitored in real time to improve the user experience. Export data quickly and easily for further analysis, improving your lab’s efficiency and data integrity. This powerful tool is an absolute necessity for any research or quality control laboratory.
At Dyrec, we are committed to empowering your business with the latest solutions. Our top-quality rotary joints are designed to optimize the performance of your equipment.
Take the next step toward success by contacting us or downloading our comprehensive product guide. Your journey toward success begins here.
Melting Point Apparatus is widely used across cosmetics, pharmaceuticals, chemicals, food, environmental testing, etc.
| Measuring range | RT to 360 °C |
| Resolution | 0.1 °C |
| Linear Heating-up Rate | 0.1 °C to 20 °C/min |
| Temperature accuracy | 0.4 °C (≤ 200°C), 0.7 °C (> 200 °C) |
| Repeatability | 0.3 °C |
| Capillary size | φ1.4 mm (outside diameter), φ1.0mm (inside diameter), 80mm (height) |
| Sample loading height | 3 mm |
| Data storage | 1000 sets |
| Power supply | AC 110/220V ±10%, 50/60Hz |
| Exterior dimension (W × D × H) | 360 × 290 × 270 mm |
| Packing dimension (W × D × H) | 580 × 430 × 310 mm |
| Gross weight | 13 Kg |
