Measuring microscope FM-PMM-A102 comes with small, lightweight, portable design, and user-friendly operations. Equipped with No. 7 pen battery as source of illumination during microscopic analysis. Different measurements are possible by using different reticules and eyepiece using this microscope.
At Dyrec, we are committed to empowering your business with the latest solutions. Our top-quality rotary joints are designed to optimize the performance of your equipment.
Take the next step toward success by contacting us or downloading our comprehensive product guide. Your journey toward success begins here.
Used in on field microscopic measurement or viewing across machinery production industry, paper and printing, textile industry for quality and research purpose.
| Total magnification | 40X |
| Objective | Achromatic objective 4X |
| Condenser | N.A. 0.1 |
| Illumination source | Pen light, no. 7 battery (with Holder) |
| Eyepiece/ cross with reticle | WF 10X/ 18 mm (with diopter adjustment) |
| Magnification tube length | 160 mm |
| Eyepiece reticle | 0.1 mm |
| Fine division | 0.025 mm |
| Working distance | 18 mm |
| Focus range | 30 mm |
| Diameter of bearing plane | 63 mm |
| Height of microscope | 210 mm |
| Weight | 650 g |
