Horizontal Steam Sterilizer FM-HSS-A100 has a 150-liter capacity, making it suitable for large-scale sterilization tasks. It includes an optional micro printer for convenient data logging and record keeping. The safety door interlock feature prevents accidental opening during cycles, enhancing user safety. Our sterilizer has electronic circuit protection, providing reliable performance and durability.
At Dyrec, we are committed to empowering your business with the latest solutions. Our top-quality rotary joints are designed to optimize the performance of your equipment.
Take the next step toward success by contacting us or downloading our comprehensive product guide. Your journey toward success begins here.
Horizontal Steam Sterilizer FM-HSS-A100 is a high-capacity sterilization device for efficient disinfection across various industries. It is widely used in hospitals, laboratories, and industrial settings to sterilize medical instruments, laboratory equipment, and tools.
| Capacity | 150 L |
| Design Pressure | 0.3 Mpa |
| Working Pressure | 0.23 Mpa |
| Pressure Display Accuracy | 0.1 kPa |
| Sterilization Temperature | 105 to 136°C |
| Temperature Display Accuracy | 0.1°C |
| Maximum Temperature | 136°C |
| Temperature Uniformity | ≤±0.5°C |
| Power Consumption | 12 kW |
| Power Supply | 380 V/220 V, 50 Hz |
| Chamber Size (Φ × L) | 500 × 780 mm |
| Dimensions (L × W × H) | 1080 × 750 × 1750 mm |
| Packaging Dimensions (L × W × H) | 1300 × 1000 × 1950 mm |
| Net Weight | 215 kg |
| Gross Weight | 360 kg |
