Ducted Fume Hood FM-PDF-A202 features a work surface height of 750mm, providing a comfortable working posture for the operator. This offers an adjustable airflow system, that calibrates air velocity to meet requirements. It has a high system exhaust volume, ensuring the removal of airborne contaminants. Our Ducted Fume Hood features a microprocessor control system for precise operation management.
At Dyrec, we are committed to empowering your business with the latest solutions. Our top-quality rotary joints are designed to optimize the performance of your equipment.
Take the next step toward success by contacting us or downloading our comprehensive product guide. Your journey toward success begins here.
Ducted Fume Hood FM-PDF-A202 is ideal for laboratories handling hazardous chemicals, fumes, and toxic gases. It is commonly used in research, pharmaceutical, chemical, and industrial environments for safe ventilation and containment.
| Work Surface Height | 750mm |
| Air Velocity | 0.3 to 0.8m/s |
| Noise | ≤ 68dB |
| LED Lamp | 16W×1 |
| UV Lamp | 30W |
| Blower | Built-in centrifugal blowers, speed adjustable with 9 levels |
| Front Window | Motorized, 5mm toughened glass, anti-UV |
| Material Exterior | Cold-rolled steel with anti-bacteria powder coating |
| Material Work Table | Chemical resistant phenolic resin |
| Waterproof Sockets | 2pcs |
| System Exhaust Volume | 990m³/h |
| Power Supply | AC220V±10%, 50/60Hz; 110V±10%, 60Hz |
| Power Consumption | 500W |
| Dimensions (W×D×H) | 1650×1120×1680mm |
| Internal Dimension (W×D×H) | 1380×730×745mm |
| External Dimension (W×D×H) | 1500×840×2150mm |
| Weight | 290kg |
