Drying Oven FM-DO-A106

SKU: e9da4a9b7bfc Categories: Lab Equipment, Oven Brand: Fison

Drying Oven FM-DO-A106 operates on a forced convection cycling mode, offering a temperature range of RT + 10 to 300 ℃. Designed for user convenience, it features an LCD temperature controller for smooth operation. Users can adjust the fan speed according to the experiment’s requirements. Moreover, it is equipped with an integrated over-temperature protection system, ensuring safety by preventing overheating. Its robust 304 stainless steel body not only provides durability but also offers corrosion resistance.

Maximize Your Machine Potential

At Dyrec, we are committed to empowering your business with the latest solutions. Our top-quality rotary joints are designed to optimize the performance of your equipment.

Take the next step toward success by contacting us or downloading our comprehensive product guide. Your journey toward success begins here.

Description

Features

Drying Oven comprises anti-hot handle
Double air ducts ensure efficient air circulation
PID controller maintains precise temperature
User-friendly interface includes fan switch and LED display
Adjustable airflow with a 4-speed fan caters
High precision digital temperature limiter

Applications

Drying Oven maintains precise temperature control and uniformity across industries like biotechnology, food, pharmaceuticals, textile, and agriculture.

Chamber volume	125 L
Method	Forced convection
Temperature Range	RT + 10 to 300 ℃
Temperature Resolution	0.1 ℃
Temperature Motion	±1 ℃
Temperature Uniformity	±2.5%
Temperature Sensor	PT100
Temperature controller	Two temperature section PID intelligent, Touch type function
Temperature display	LCD
Interior Material	Mirror Stainless Steel
Exterior Material	Cold rolling steel electrostatic spraying exterior
Insulation Material	High quality rock wool board
Heater	Stainless steel heater
Power rating	2.3 kW
Exhaust hole	Φ 35 mm
Timer	0 to 9999 min
Operation function	Fixed temperature operation, Timing function, Auto stop
Max Shelf number	11
Load per rack	15 Kg
Shelf space	40 mm
Shelves	2
Shelf frame	4
Power rating (50/60HZ)	AC220V/10.5A
Interior dimension (W × L × H)	500 × 450 × 550 mm
Exterior dimension (W × L × H)	640 × 640 × 930 mm
Packaging dimension (W × L × H)	710 × 730 × 1100 mm
Net weight	60 Kg
Gross Weight	66 Kg
