Automatic Tissue Slide Stainer FM-ATS-A100 is a fully automated slide stainer comprised with intelligent water inlet and outlet control system, offers 14 cups with 1200 ml capacity of each. With 0 to 59 min of processing time and 0 to 59 s of dripping time, features automatic drying function and intelligent control of hot air system with leaching function. Ergonomic design with 5.5-inch LCD touch screen, self-checking function and customizable dyeing treatment method, supports adjustable tank surface drainage time along with 8 programs storage capacity and 24 programmable orders. With real-time display of working parameters, environmentally friendly external exhaust air purification system, and fully enclosed structure, supports wrong function reminder along with automatic handling of abnormal situation.
At Dyrec, we are committed to empowering your business with the latest solutions. Our top-quality rotary joints are designed to optimize the performance of your equipment.
Take the next step toward success by contacting us or downloading our comprehensive product guide. Your journey toward success begins here.
Automatic Tissue slide stainer is used to automate the staining of peripheral blood and other hematologic smears with identical or different staining protocols across cytology, histology, immunology, microbiology, biotechnology, fisheries, research & medical institutes, pharmaceuticals, etc.
| Cup number | 14 (station 1 for drying & station 8 for washing) |
| Cup capacity | 1200 ml |
| Cup processing time | 0 to 59 min |
| No. of slides processed | 72 slides |
| Dripping time | 0 to 50 s |
| Display | 5.5-inch LCD touch screen |
| Purification system | External exhaust air purification system |
| Drying function | Automatic |
| Dyeing treatment method | Custom |
| Programmable order | 24 |
| Storage | 8 sets |
| Reminder system | Wrong function |
| Power supply | AC 220/110 V ± 10%, 50/60 Hz |
| Power | ≤ 1000 W |
| Dimension (W×D×H) | 1200×480×450 mm |
| Packaging dimension (W×D×H) | 1430×600×750 mm |
| Net weight | 80 kg |
| Gross weight | 100 kg |
