Auto Digital Refractometer FM-ADR-A100 is an automated, benchtop unit comprised with high resolution CCD detector, offers refractive index measuring range of 1.30000 to 1.70000 and brix measurement of 0 to 100%. With 5 to 80°C of temperature control range and high measuring resolution up to 0.00001 nD/ 0.01% Brix, features sapphire glass prism and built-in Peltier temperature control system. Designed with LED light source and 7-inch color touch screen, has LINUX operating system along with 4 GB of data storage capacity. With interface communication via RS232, USB, SD card, U-disk, internet and Wi-Fi, this refractometer also supports compliance with FDA 21 CFR part 11.
At Dyrec, we are committed to empowering your business with the latest solutions. Our top-quality rotary joints are designed to optimize the performance of your equipment.
Take the next step toward success by contacting us or downloading our comprehensive product guide. Your journey toward success begins here.
Digital refractometer is used for rapid and accurate determination of the index of refraction of liquid samples, and to measure fluid concentrations, such as blood protein concentration, sugar content, and salinity across oil, pharmaceutical, paint, food, chemical, sugar, and petroleum industries etc.
| Measuring range | 1.30000 to 1.70000 nD |
| Brix range | 0 to 100% |
| Temperature measure range | 0 to 100°C |
| Temperature control range | 5 to 80°C |
| Temperature accuracy | ± 0.02°C |
| Measured value error | ± 0.0001 nD |
| Measured value resolution | 0.0001/0.00001 nD |
| Brix error | ± 0.1% |
| Brix resolution | 0.1%/0.01% |
| Detector | High resolution CCD detector |
| Measuring prism | Sapphire glass |
| Temperature control system | Built-in Peltier temperature control system |
| Display | 7-inch color touch screen |
| Light source | LED light source |
| Operating system | LINUX |
| Data storage | 4 GB |
| Interface | RS232, USB, SD card, U-disk, internet and Wi-Fi |
| Power supply | 110 to 240 V (12 V, 10 A) |
| Power | 45 W |
| Dimension (W×D×H) | 365×300×150 mm |
| Net Weight | 8 kg |
| Packaging dimension (W×D×H) | 500×420×330 mm |
| Gross weight | 10 kg |
